WAS Node Suite - ComfyUI - WAS#0263

ComfyUI is an advanced node based UI utilizing Stable Diffusion. It allows you to create customized workflows such as image post processing, or conversions.

Latest Version Download

A node suite for ComfyUI with many new nodes, such as image processing, text processing, and more.

Share Workflows to the workflows wiki. Preferably embedded PNGs with workflows, but JSON is OK too. You can use this tool to add a workflow to a PNG file easily

Important Updates

[Updated 5/29/2023] ASCII is deprecated. The new preferred method of text node output is STRING. This is a change from ASCII so that it is more clear what data is being passed.
- The was_suite_config.json will automatically set use_legacy_ascii_text to false.
Video Nodes - There are two new video nodes, Write to Video and Create Video from Path. These are experimental nodes.

Current Nodes:

BLIP Analyze Image: Get a text caption from a image, or interrogate the image with a question.
- Model will download automatically from default URL, but you can point the download to another location/caption model in was_suite_config
- Models will be stored in ComfyUI/models/blip/checkpoints/
SAM Model Loader: Load a SAM Segmentation model
SAM Parameters: Define your SAM parameters for segmentation of a image
SAM Parameters Combine: Combine SAM parameters
SAM Image Mask: SAM image masking
Image Bounds: Bounds a image
Inset Image Bounds: Inset a image bounds
Bounded Image Blend: Blend bounds image
Bounded Image Blend with Mask: Blend a bounds image by mask
Bounded Image Crop: Crop a bounds image
Bounded Image Crop with Mask: Crop a bounds image by mask
Cache Node: Cache Latnet, Tensor Batches (Image), and Conditioning to disk to use later.
CLIPTextEncode (NSP): Parse noodle soups from the NSP pantry, or parse wildcards from a directory containing A1111 style wildacrds.
- Wildcards are in the style of __filename__, which also includes subdirectories like __appearance/haircolour__ (if you noodle_key is set to __)
- You can set a custom wildcards path in was_suite_config.json file with key:
  - "wildcards_path": "E:\\python\\automatic\\webui3\\stable-diffusion-webui\\extensions\\sd-dynamic-prompts\\wildcards"
  - If no path is set the wildcards dir is located at the root of WAS Node Suite as /wildcards
Conditioning Input Switch: Switch between two conditioning inputs.
Constant Number
Create Grid Image: Create a image grid from images at a destination with customizable glob pattern. Optional border size and color.
Create Morph Image: Create a GIF/APNG animation from two images, fading between them.
Create Morph Image by Path: Create a GIF/APNG animation from a path to a directory containing images, with optional pattern.
Create Video from Path: Create video from images from a specified path.
CLIPSeg Masking: Mask a image with CLIPSeg and return a raw mask
CLIPSeg Masking Batch: Create a batch image (from image inputs) and batch mask with CLIPSeg
Dictionary to Console: Print a dictionary input to the console
Image Analyze
- Black White Levels
- RGB Levels
  - Depends on matplotlib, will attempt to install on first run
Diffusers Hub Down-Loader: Download a diffusers model from the HuggingFace Hub and load it
Image Batch: Create one batch out of multiple batched tensors.
Image Blank: Create a blank image in any color
Image Blend by Mask: Blend two images by a mask
Image Blend: Blend two images by opacity
Image Blending Mode: Blend two images by various blending modes
Image Bloom Filter: Apply a high-pass based bloom filter
Image Canny Filter: Apply a canny filter to a image
Image Chromatic Aberration: Apply chromatic aberration lens effect to a image like in sci-fi films, movie theaters, and video games
Image Color Palette
- Generate a color palette based on the input image.
  - Depends on scikit-learn, will attempt to install on first run.
- Supports color range of 8-256
- Utilizes font in ./res/ unless unavailable, then it will utilize internal better then nothing font.
Image Crop Face: Crop a face out of a image
- Limitations:
  - Sometimes no faces are found in badly generated images, or faces at angles
  - Sometimes face crop is black, this is because the padding is too large and intersected with the image edge. Use a smaller padding size.
  - face_recognition mode sometimes finds random things as faces. It also requires a [CUDA] GPU.
  - Only detects one face. This is a design choice to make it's use easy.
- Notes:
  - Detection runs in succession. If nothing is found with the selected detection cascades, it will try the next available cascades file.
Image Crop Location: Crop a image to specified location in top, left, right, and bottom locations relating to the pixel dimensions of the image in X and Y coordinats.
Image Crop Square Location: Crop a location by X/Y center, creating a square crop around that point.
Image Displacement Warp: Warp a image by a displacement map image by a given amplitude.
Image Dragan Photography Filter: Apply a Andrzej Dragan photography style to a image
Image Edge Detection Filter: Detect edges in a image
Image Film Grain: Apply film grain to a image
Image Filter Adjustments: Apply various image adjustments to a image
Image Flip: Flip a image horizontal, or vertical
Image Gradient Map: Apply a gradient map to a image
Image Generate Gradient: Generate a gradient map with desired stops and colors
Image High Pass Filter: Apply a high frequency pass to the image returning the details
Image History Loader: Load images from history based on the Load Image Batch node. Can define max history in config file. (requires restart to show last sessions files at this time)
Image Input Switch: Switch between two image inputs
Image Levels Adjustment: Adjust the levels of a image
Image Load: Load a image from any path on the system, or a url starting with http
Image Median Filter: Apply a median filter to a image, such as to smooth out details in surfaces
Image Mix RGB Channels: Mix together RGB channels into a single iamge
Image Monitor Effects Filter: Apply various monitor effects to a image
- Digital Distortion
  - A digital breakup distortion effect
- Signal Distortion
  - A analog signal distortion effect on vertical bands like a CRT monitor
- TV Distortion
  - A TV scanline and bleed distortion effect
Image Nova Filter: A image that uses a sinus frequency to break apart a image into RGB frequencies
Image Perlin Noise: Generate perlin noise
Image Perlin Power Fractal: Generate a perlin power fractal
Image Paste Face Crop: Paste face crop back on a image at it's original location and size
- Features a better blending funciton than GFPGAN/CodeFormer so there shouldn't be visible seams, and coupled with Diffusion Result, looks better than GFPGAN/CodeFormer.
Image Paste Crop: Paste a crop (such as from Image Crop Location) at it's original location and size utilizing the crop_data node input. This uses a different blending algorithm then Image Paste Face Crop, which may be desired in certain instances.
Image Power Noise: Generate power-law noise
- frequency: The frequency parameter controls the distribution of the noise across different frequencies. In the context of Fourier analysis, higher frequencies represent fine details or high-frequency components, while lower frequencies represent coarse details or low-frequency components. Adjusting the frequency parameter can result in different textures and levels of detail in the generated noise. The specific range and meaning of the frequency parameter may vary depending on the noise type.
- attenuation: The attenuation parameter determines the strength or intensity of the noise. It controls how much the noise values deviate from the mean or central value. Higher values of attenuation lead to more significant variations and a stronger presence of noise, while lower values result in a smoother and less noticeable noise. The specific range and interpretation of the attenuation parameter may vary depending on the noise type.
- noise_type: The tyoe of Power-Law noise to generate (white, grey, pink, green, blue)
Image Paste Crop by Location: Paste a crop top a custom location. This uses the same blending algorithm as Image Paste Crop.
Image Pixelate: Turn a image into pixel art! Define the max number of colors, the pixelation mode, the random state, and max iterations, and max those sprites shine.
Image Remove Background (Alpha): Remove the background from a image by threshold and tolerance.
Image Remove Color: Remove a color from a image and replace it with another
Image Resize
Image Rotate: Rotate an image
Image Save: A save image node with format support and path support. (Bug: Doesn't display image
Image Seamless Texture: Create a seamless texture out of a image with optional tiling
Image Select Channel: Select a single channel of an RGB image
Image Select Color: Return the select image only on a black canvas
Image Shadows and Highlights: Adjust the shadows and highlights of an image
Image Size to Number: Get the width and height of an input image to use with Number nodes.
Image Stitch: Stitch images together on different sides with optional feathering blending between them.
Image Style Filter: Style a image with Pilgram instragram-like filters
- Depends on pilgram module
Image Threshold: Return the desired threshold range of a image
Image Tile: Split a image up into a image batch of tiles. Can be used with Tensor Batch to Image to select a individual tile from the batch.
Image Transpose
Image fDOF Filter: Apply a fake depth of field effect to an image
Image to Latent Mask: Convert a image into a latent mask
Image to Noise: Convert a image into noise, useful for init blending or init input to theme a diffusion.
Image to Seed: Convert a image to a reproducible seed
Image Voronoi Noise Filter
- A custom implementation of the worley voronoi noise diagram
Input Switch (Disable until * wildcard fix)
KSampler (WAS): A sampler that accepts a seed as a node inpu
Load Cache: Load cached Latent, Tensor Batch (image), and Conditioning files.
Load Text File
- Now supports outputting a dictionary named after the file, or custom input.
- The dictionary contains a list of all lines in the file.
Load Batch Images
- Increment images in a folder, or fetch a single image out of a batch.
- Will reset it's place if the path, or pattern is changed.
- pattern is a glob that allows you to do things like **/* to get all files in the directory and subdirectory or things like *.jpg to select only JPEG images in the directory specified.
Mask to Image: Convert MASK to IMAGE
Mask Batch to Mask: Return a single mask from a batch of masks
Mask Invert: Invert a mask.
Mask Add: Add masks together.
Mask Subtract: Subtract from a mask by another.
Mask Dominant Region: Return the dominant region in a mask (the largest area)
Mask Minority Region: Return the smallest region in a mask (the smallest area)
Mask Arbitrary Region: Return a region that most closely matches the size input (size is not a direct representation of pixels, but approximate)
Mask Smooth Region: Smooth the boundaries of a mask
Mask Erode Region: Erode the boundaries of a mask
Mask Dilate Region: Dilate the boundaries of a mask
Mask Fill Region: Fill holes within the masks regions
Mask Ceiling Region": Return only white pixels within a offset range.
Mask Floor Region: Return the lower most pixel values as white (255)
Mask Threshold Region: Apply a thresholded image between a black value and white value
Mask Gaussian Region: Apply a Gaussian blur to the mask
Masks Combine Masks: Combine 2 or more masks into one mask.
Masks Combine Batch: Combine batched masks into one mask.
ComfyUI Loaders: A set of ComfyUI loaders that also output a string that contains the name of the model being loaded.
Latent Noise Injection: Inject latent noise into a latent image
Latent Size to Number: Latent sizes in tensor width/height
Latent Upscale by Factor: Upscale a latent image by a factor
Latent Input Switch: Switch between two latent inputs
Logic Boolean: A simple 1 or 0 output to use with logic
MiDaS Depth Approximation: Produce a depth approximation of a single image input
MiDaS Mask Image: Mask a input image using MiDaS with a desired color
Number Operation
Number to Seed
Number to Float
Number Input Switch: Switch between two number inputs
Number Input Condition: Compare between two inputs or against the A input
Number to Int
Number to String
Number to Text
Random Number
Save Text File: Save a text string to a file
Seed: Return a seed
Tensor Batch to Image: Select a single image out of a latent batch for post processing with filters
Text Add Tokens: Add custom tokens to parse in filenames or other text.
Text Add Token by Input: Add custom token by inputs representing single single line name and value of the token
Text Compare: Compare two strings. Returns a boolean if they are the same, a score of similarity, and the similarity or difference text.
Text Concatenate: Merge two strings
Text Dictionary Update: Merge two dictionaries
Text File History: Show previously opened text files (requires restart to show last sessions files at this time)
Text Find and Replace: Find and replace a substring in a string
Text Find and Replace by Dictionary: Replace substrings in a ASCII text input with a dictionary.
- The dictionary keys are used as the key to replace, and the list of lines it contains chosen at random based on the seed.
Text Input Switch: Switch between two text inputs
Text List: Create a list of text strings
Text Concatenate: Merge lists of strings
Text Multiline: Write a multiline text string
Text Parse A1111 Embeddings: Convert embeddings filenames in your prompts to embedding:[filename]] format based on your /ComfyUI/models/embeddings/ files.
Text Parse Noodle Soup Prompts: Parse NSP in a text input
Text Parse Tokens: Parse custom tokens in text.
Text Random Line: Select a random line from a text input string
Text String: Write a single line text string value
Text to Conditioning: Convert a text string to conditioning.
True Random.org Number Generator: Generate a truly random number online from atmospheric noise with Random.org
- Get your API key from your account page
Write to Morph GIF: Write a new frame to an existing GIF (or create new one) with interpolation between frames.
Write to Video: Write a frame as you generate to a video (Best used with FFV1 for lossless images)

Extra Nodes

CLIPTextEncode (BlenderNeko Advanced + NSP): Only available if you have BlenderNeko's Advanced CLIP Text Encode. Allows for NSP and Wildcard use with their advanced CLIPTextEncode.

Video Nodes

Codecs

You can use codecs that are available to your ffmpeg binaries by adding their fourcc ID (in one string), and appropriate container extension to the was_suite_config.json

Example H264 Codecs (Defaults)

    "ffmpeg_extra_codecs": {
        "avc1": ".mp4",
        "h264": ".mkv"
    }

Notes

For now I am only supporting Windows installations for video nodes.
- I do not have access to Mac or a stand-alone linux distro. If you get them working and want to PR a patch/directions, feel free.
Video nodes require FFMPEG. You should download the proper FFMPEG binaries for you system and set the FFMPEG path in the config file.
Additionally, if you want to use H264 codec need to download OpenH264 1.8.0 and place it in the root of ComfyUI (Example: C:\ComfyUI_windows_portable).
FFV1 will complain about invalid container. You can ignore this. The resulting MKV file is readable. I have not figured out what this issue is about. Documentaion tells me to use MKV, but it's telling me it's unsupported.
- If you know how to resolve this, I'd love a PR
Write to Video node should use a lossless video codec or when it copies frames, and reapplies compression, it will start expontentially ruining the starting frames run to run.

Text Tokens

Text tokens can be used in the Save Text File and Save Image nodes. You can also add your own custom tokens with the Text Add Tokens node.

The token name can be anything excluding the : character to define your token. It can also be simple Regular Expressions.

Built-in Tokens

[time]
- The current system microtime
[time(format_code)]
- The current system time in human readable format. Utilizing datetime formatting
- Example: [hostname]_[time]__[time(%Y-%m-%d__%I-%M%p)] would output: SKYNET-MASTER_1680897261__2023-04-07__07-54PM
[hostname]
- The hostname of the system executing ComfyUI
[user]
- The user that is executing ComfyUI

Other Features

Import AUTOMATIC1111 WebUI Styles

When using the latest builds of WAS Node Suite a was_suite_config.json file will be generated (if it doesn't exist). In this file you can setup a A1111 styles import.

Run ComfyUI to generate the new /custom-nodes/was-node-suite-comfyui/was_Suite_config.json file.
Open the was_suite_config.json file with a text editor.
Replace the webui_styles value from None to the path of your A1111 styles file called styles.csv. Be sure to use double backslashes for Windows paths.
- Example C:\\python\\stable-diffusion-webui\\styles.csv
Restart ComfyUI
Select a style with the Prompt Styles Node.
- The first ASCII output is your positive prompt, and the second ASCII output is your negative prompt.

You can set webui_styles_persistent_update to true to update the WAS Node Suite styles from WebUI every start of ComfyUI

Recommended Installation:

If you're running on Linux, or non-admin account on windows you'll want to ensure /ComfyUI/custom_nodes, was-node-suite-comfyui, and WAS_Node_Suite.py has write permissions.

Navigate to your /ComfyUI/custom_nodes/ folder
Run git clone https://github.com/WASasquatch/was-node-suite-comfyui/
Navigate to your was-node-suite-comfyui folder
- Portable/venv:
  - Run path/to/ComfUI/python_embeded/python.exe -m pip install -r requirements.txt
- With system python
  - Run pip install -r requirements.txt
Start ComfyUI
- WAS Suite should uninstall legacy nodes automatically for you.
- Tools will be located in the WAS Suite menu.

Alternate Installation:

If you're running on Linux, or non-admin account on windows you'll want to ensure /ComfyUI/custom_nodes, and WAS_Node_Suite.py has write permissions.

Download WAS_Node_Suite.py
Move the file to your /ComfyUI/custom_nodes/ folder
WAS Node Suite will attempt install dependencies on it's own, but you may need to manually do so. The dependencies required are in the requirements.txt on this repo. See installation steps above.
Start, or Restart ComfyUI
- WAS Suite should uninstall legacy nodes automatically for you.
- Tools will be located in the WAS Suite menu.

This method will not install the resources required for Image Crop Face node, and you'll have to download the ./res/ folder yourself.

Installing on Colab

Create a new cell and add the following code, then run the cell. You may need to edit the path to your custom_nodes folder. You can also use the colab hosted here

!git clone https://github.com/WASasquatch/was-node-suite-comfyui /content/ComfyUI/custom_nodes/was-node-suite-comfyui
Restart Colab Runtime (don't disconnect)
- Tools will be located in the WAS Suite menu.

Github Repository: https://github.com/WASasquatch/was-node-suite-comfyui

❤ Hearts and 🖼️ Reviews let me know you want moarr! :3

Description

Updates:

Various patches to nodes.
ASCII is fully deprecated and new TEXT_TYPE is STRING
Dependency changes, be sure to re-run the requirements.txt with the Python executable that ComfyUI uses (such as the one at /python_embedded/python.exe for ComfyUI Portable)

New Nodes:

CLIPSeg Masking: Mask a image with CLIPSeg and return a raw mask

CLIPSeg Masking Batch: Create a batch image (from image inputs) and batch mask with CLIPSeg
Diffusers Hub Down-Loader: Download a diffusers model from the HuggingFace Hub and load it
Image Batch: Create one batch out of multiple batched tensors.
Image Crop Square Location: Crop a location by X/Y center, creating a square crop around that point.
Image Displacement Warp: Warp a image by a displacement map image by a given amplitude.
Image Perlin Noise: Generate perlin noise
Image Perlin Power Fractal: Generate a perlin power fractal
Image Paste Face Crop: Paste face crop back on a image at it's original location and size
Image Paste Crop: Paste a crop (such as from Image Crop Location) at it's original location and size utilizing the crop_data node input. This uses a different blending algorithm then Image Paste Face Crop, which may be desired in certain instances.
Image Power Noise: Generate power-law noise
Image Paste Crop by Location: Paste a crop top a custom location. This uses the same blending algorithm as Image Paste Crop.
Image Pixelate: Turn a image into pixel art! Define the max number of colors, the pixelation mode, the random state, and max iterations, and max those sprites shine.
Image Tile: Split a image up into a image batch of tiles. Can be used with Tensor Batch to Image to select a individual tile from the batch.
Image to Noise: Convert a image into noise, useful for init blending or init input to theme a diffusion.
Image to Seed: Convert a image to a reproducible seed
Mask Batch to Mask: Return a single mask from a batch of masks
Mask Invert: Invert a mask.
Mask Add: Add masks together.
Mask Subtract: Subtract from a mask by another.
Mask Ceiling Region": Return only white pixels within a offset range.
Mask Floor Region: Return the lower most pixel values as white (255)
Mask Threshold Region: Apply a thresholded image between a black value and white value
Mask Gaussian Region: Apply a Gaussian blur to the mask
Masks Combine Masks: Combine 2 or more masks into one mask.
Masks Combine Batch: Combine batched masks into one mask.
Text List: Create a list of text strings
Text Concatenate: Merge lists of strings

FAQ

Comments (46)

navimixuMay 30, 2023· 2 reactions

CivitAI

im planning to start learn using ComfyUI, thanx for the starterpack 😍
